Benefits

- Hydraulically adjustable jaw setting to maximize your output

- Reverse crushing action to crush sticky material or relieve blockages

- Hydraulic drive enabling the crusher to start under load, minimizing downtime

- Jaw level sensor available to control feed rate with minimal intervention

- Raise/lower facility on the main conveyor

Specification

Capacity- 400 tph
Weight- 45,233 kg (99,722 lb)
Feed opening-1,200 x 750 mm (47 in. x 29 in.)
Optimum feed size-650 mm (25 ⅝ in.)
Transport length-14.05 m (46 ft 1 ¼ in.)
Transport width- 2.86 m (9 ft 4 ½ in.)
Transport height- 3.45 m (11 ft 3 ⅝ in.)
Working Length- 15.81 m (51 ft 10 ½ in.)
Working Width- 3.50 m (11 ft 6 in.)
Working Height- 4.44 m (14 ft 7 in.)

Premiertrak 400X/R400X

The Powerscreen® Premiertrak 400X range of high performance primary jaw crushing plants are designed for medium scale operators in quarrying, demolition, recycling and mining applications. The range includes the Premiertrak 400X with hydraulic adjust and the Premiertrak R400X with hydraulic release. Benefits include track mobility for a quick set-up time (typically under 30 minutes,) hydraulic crusher setting adjustment for total control of product size and crusher overload protection to prevent damage by uncrushable objects.

Weight-(Est)(Tier 3) 46,300kgs (102,274lbs)  (Tier 4F) 46,500kg(102,514lbs)
Transport width- 2.8m (9'2")
Transport length- 15.02m (49'3")
Transport height- 3.4m (11'2")
Working width-4.33m (14'2") (with side conveyor)
Working length-14.66m (48'1")
Working height- 4.13m (13'6")

Click for more information

Click for more information

Click for more information

Benefits-

Output potential - up to 200tph (220 US tph)*

Heavy duty fabricated chassis and track frame

Heavy duty wear resistant feed hopper

Fixed hopper as standard with bolt-in wear liners

Stepped self-cleaning grizzly feeder

Fully skirted product conveyor up to magnet

Grizzly bypass and fines chute

Centralised hydraulics and electrics

Dust suppression system

Economical to operate with a highly fuel efficient direct drive system

Powerscreen Pulse Intelligence telemetry system as standard

Specification

Weight (Est.)(Tier 3) 27,920kg (61,553lbs)   (Tier 4 Final) 28,200kg (62,170lbs)
Transport width- 2.4m (7' 10")
Transport length- 12.4m (40’ 8’’)
Transport height- 3.2m (10’ 6”)
Working width- 3.8m (12’ 6”) with bypass conveyor
Working length- 12.4m (40’ 8”)
Working height- 3.2m (10’ 6”)

Weight (Est): 46,500kg (102,514lbs)
Transport width: 2.8m (9'2")
Transport length: 15.02m (49'3")
Transport height: 3.4m (11'2")
Working width: 4.33m (14'2") (with side conveyor)
Working length: 14.66m (48'1")
Working height: 4.13m (13'6")
