Our QE341 is the most advanced, heavy duty, tracked mobile scalping screen on the market. We have designed it to handle your most difficult infeed material with a wide hopper opening, aggressive screenbox and oversize conveyor. This also ensures a free flow of material from front to back.

The QE341 features a double-plated apron feeder as standard, ensuring it can handle heavy duty scalping applications. The middle and over size conveyors can be hydraulically lowered to feed material into a cone or primary.

Features

  • Operator safety ensured with radio tracking and feeder control as standard
  • Uniquely aggressive screenbox with 9mm of throw at over 1000 rpm
  • Hydraulic folding maintenance platforms for ease of service and maintenance
  • Easy operation through a unique colour-coded control panel with one touch start/stop
  • Optimum fuel economy at less than 15 l/hour to lower your operating costs

Key Specifications

  • Screen Box 16' x 5' / 4.7 x 1.45 m
  • Engine C4.4 74.5 kW / 100 hp
  • Transport Length 14.84 m / 48' 8"
  • Transport Width 3.00 m / 9' 10"
  • Transport Height 3.40 m / 11' 2"
  • Weight 29,770 kg / 65,631 lbs
